Diamond Saw Blade
Segmented Series
The TUSKO Segmented Series diamond saw blade uses advanced hot-pressed sintering technology with premium-grade diamond segments. Designed for heavy-duty cutting of paving slabs, concrete, bricks and roofing tiles, it delivers exceptional durability and cutting efficiency.
Paving slabs, concrete, bricks and roofing tiles
7mm or 10mm hot sintered diamond segments
Blade material: 1.75Cr1 premium steel
Available in 115mm to 350mm diameters
Applications
ConcreteBrickPaving SlabsRoofing Tiles
Technical Specifications
| Item No. | Diameter (mm) | Diameter (in) | Layer 1 (mm) | Layer 2 (mm) | Height 1 (mm) | Height 2 (mm) | Hole (mm) |
|---|---|---|---|---|---|---|---|
| TS115 | 115 | 4 1/2" | 2 | 2 | 7 | 10 | 22.2 |
| TS125 | 125 | 5" | 2 | 2 | 7 | 10 | 22.2 |
| TS150 | 150 | 6" | 2 | 2.4 | 7 | 10 | 22.2 |
| TS180 | 180 | 7" | 2 | 2.4 | 7 | 10 | 22.2 |
| TS230 | 230 | 9" | 2 | 3 | 7 | 10 | 22.2 |
| TS300 | 300 | 12" | 2 | 3 | 10 | 10 | 22.2 |
| TS350 | 350 | 14" | 2 | 3.2 | 10 | 10 | 25.4 |
Custom Solutions Available
TUSKO offers full OEM/ODM customization. Contact our technical team for custom sizes,
diamond grit specifications, segment heights, and special applications.
